Digital camera

The concept of digitizing images on scanners, and the concept of digitizing video signals, predate the concept of making still pictures by digitizing signals from an array of discrete sensor elements. Eugene F. Lally of the Jet Propulsion Laboratory published the first description of how to produce still photos in a digital domain using a mosaic photosensor. The purpose was to provide onboard navigation information to astronauts during missions to planets. The mosaic array periodically recorded still photos of star and planet locations during transit and when approaching a planet provided additional stadiametric information for orbiting and landing guidance. The concept included camera design elements foreshadowing the first digital camera.

Texas Instruments designed a filmless analog camera in 1972, but it is not known if it was ever built. The first recorded attempt at building a digital camera was by Steven Sasson, an engineer at Eastman Kodak. It used the then-new solid state CCD chips developed by Fairchild Semiconductor in 1973. The camera weighed 8 pounds (3.6 kg), recorded black and white images to a cassette tape, had a resolution of 0.01 megapixel (10,000 pixels), and took 23 seconds to capture its first image in December of 1975. The prototype camera was a technical exercise, not intended for production, and it still existed as of 2007.

Analog cameras do not appear to have reached the market until 1986 with the Canon RC-701. Canon demonstrated this model at the 1984 Olympics, printing the images in newspapers. Several factors held back the widespread adoption of analog cameras; the cost (upwards of $20,000), poor image quality compared to film, and the lack of quality affordable printers. Capturing and printing an image originally required access

The early adopters tended to be in the news media, where the cost was negated by the utility and the ability to transmit images by telephone lines. The poor image quality was offset by the low resolution of newspaper graphics. This capability to transmit images without a satellite link was useful during the Tiananmen Square protests of 1989 and the first Gulf War in 1991.

The first analog camera marketed to consumers may have been the Canon RC-250 Xapshot in 1988. A notable analog camera produced the same year was the Nikon QV-1000C, designed as a press camera and not offered for sale to general users, which sold only a few hundred units. It recorded images in greyscale, and the quality in newspaper print was equal to film cameras. In appearance it closely resembled a modern digital single-lens reflex camera. Images were stored on video floppy disks.

The move to digital formats was helped by the formation of the first JPEG and MPEG standards in 1988, which allowed image and video files to be compressed for storage. The first consumer camera with a liquid crystal display on the back was the Casio QV-10 in 1995, and the first camera to use CompactFlash was the Kodak DC-25 in 1996.

The marketplace for consumer digital cameras was originally low resolution (either analog or digital) cameras built for utility. In 1997 the first megapixel cameras for consumers were marketed. The first camera that offered the ability to record video clips may have been the Ricoh RDC-1 in 1995.

1999 saw the introduction of the Nikon D1, a 2.74 megapixel camera that was the first digital SLR developed entirely by a major manufacturer, and at a cost of under $6,000 at introduction was affordable by professional photographers and high end consumers. This camera also used Nikon F-mount lenses, which meant film photographers could use many of the same lenses they already owned.

Video cameras

Video cameras are classified as devices whose main purpose is to record moving images.

Professional video cameras such as those used in television and movie production. These typically have multiple image sensors (one per color) to enhance resolution and color gamut. Professional video cameras usually do not have a built-in VCR or microphone.

Camcorders used by amateurs. They generally include a microphone to record sound, and feature a small liquid crystal display to watch the video during taping and playback.

Webcams are digital cameras attached to computers, used for video conferencing or other purposes. Webcams can capture full-motion video as well, and some models include microphones or zoom ability. In addition, many Live-Preview Digital cameras have a "movie" mode, in which images are continuously acquired at a frame rate sufficient for video.

Live-preview digital cameras

The term digital still camera (DSC) most commonly refers to the class of live-preview digital cameras, cameras that use an electronic screen as the principal means of framing and previewing before taking the photograph. All use either a charge-coupled device (CCD) or a CMOS image sensor to sense the light intensities across the focal plane.

Many modern live-preview cameras have a movie mode, and a growing number of camcorders can take still photographs. However, even a low-end live-preview camera can take better still pictures than a mid-range video camera, and mid-range live-preview cameras have much lower video quality than low-end video cameras; that is, products are not generally optimized for both still and video photography, due to their different requirements.

Among live-preview cameras, most have a rear liquid crystal display for both preview and reviewing photographs. Transfers to a computer are commonly carried out using the USB mass storage device class (so that the camera appears as a drive) or using the Picture Transfer Protocol (PTP) and its derivatives; in addition, Firewire is sometimes supported.The live-preview cameras are typically divided into compact (and subcompact) and bridge (or prosumer) cameras.

Compact digital cameras

Also called digicams, this encompasses most digital cameras. They are characterized by great ease in operation and easy focusing; this design allows for limited motion picture capability. They tend to have significantly smaller zooms than prosumer and DSLR cameras. They have an extended depth of field. This allows objects at a larger range of depths to be in focus, which accounts for much of their ease of use. It is also part of the reason professional photographers find their images flat or artificial-looking. They excel in landscape photography and casual use. They typically save pictures in only the JPEG file format. All but the cheapest models have a built-in flash, although its guide number tends to be very low, perhaps just 6 or 8.

Bridge cameras

Prosumer or bridge or SLR-like cameras form a general group of higher-end live-preview cameras that physically resemble DSLRs and share with these some advanced features, but share with compacts the live-preview design and small sensor sizes. Traditionally, DSLRs are considered much more professional than bridge cameras, which have so far been prosumer or at best semi-professional. The new class of DSLRs can be described as consumer (compared to the higher classes of DSLRs), while the top bridge cameras remain prosumer (compared to compacts). The name prosumer from professional (or producer) and consumer, means a professional–consumer in this context.

Bridge cameras tend to have superzoom lenses, which compromises – in varying degrees, depending on the quality of the zoom lens – a "do it all" ability with barrel distortion and pincushioning. Prosumer cameras are sometimes marketed as and confused with digital SLR cameras since the bodies resemble each other. The distinguishing characteristics are that prosumer cameras lack the mirror and reflex system of DSLRs, have so far been always produced with only one single sealed (non-interchangeable) lens (but accessory wide angle or telephoto converters can be attached to the front of the sealed lens), can usually take movies, record audio and the scene composition is done with either the liquid crystal display or the electronic viewfinder (EVF). The overall performance tends to be slower than a true digital SLR, but they are capable of very good image quality while being more compact and lighter than DSLRs. The high-end models of this type have comparable resolutions to low and mid-range DSLRs. Many of the these cameras can save in JPEG or RAW format. The majority have a built-in flash, often a unit which flips up over the lens. The guide number tends to be between 11 and 15.

Digital single lens reflex cameras

Digital single-lens reflex cameras (DSLRs) are digital cameras based on film single-lens reflex cameras (SLRs), both types are characterized by the existence of a mirror and reflex system. See the main article on DSLRs for a detailed treatment of this category.

A rangefinder is a focusing mechanism once widely used on film cameras, but much less common in digital cameras. The term rangefinder alone is often used to mean a rangefinder camera, that is, a camera equipped with a rangefinder.

This category includes very high end professional equipment that can be assembled from modular components (winders, grips, lenses, etc.) to suit particular purposes. Common makes include Hasselblad and Mamiya. They were developed for medium or large format film sizes, as these captured greater detail and could be enlarged more than 35mm.

Typically these cameras are used in studios for commercial production; being bulky and awkward to carry they are rarely used in action or nature photography. They can often be converted into either film or digital use by changing out the back part of the unit, hence the use of terms such as a "digital back" or "film back." These cameras are very expensive (up to $40,000) and are typically not seen in the hands of consumers.

Conversion of film cameras to digital

When digital cameras became common, a question many photographers asked was if their film cameras could be converted to digital. The answer was yes and no. For the majority of 35 mm film cameras the answer is no, the reworking and cost would be too great, especially as lenses have been evolving as well as cameras. For the most part a conversion to digital, to give enough space for the electronics and allow a liquid crystal display to preview, would require removing the back of the camera and replacing it with a custom built digital unit.

Many early professional SLR cameras, such as the NC2000 and the Kodak DCS series, were developed from 35 mm film cameras. The technology of the time, however, meant that rather than being a digital "back" the body was mounted on a large and blocky digital unit, often bigger than the camera portion itself. These were factory built cameras, however, not aftermarket conversions. A notable exception was a device called the EFS-1, which was developed by Silicon Film from ca. 1998–2001. It was intended to insert into a film camera in the place of film, giving the camera a 1.3 MP resolution and a capacity of 24 shots. Units were demonstrated, and in 2002 the company was developing the EFS-10, a 10 MP device that was more a true digital back.

A few 35 mm cameras have had digital backs made by their manufacturer, Leica being a notable example. Medium format and large format cameras (those using film stock greater than 35 mm), have users who are capable of and willing to pay the price a low unit production digital back requires, typically over $10,000. These cameras also tend to be highly modular, with handgrips, film backs, winders, and lenses available separately to fit various needs.

The very large sensor these backs use leads to enormous image sizes. The largest in early 2006 is the Phase One's P45 39 MP imageback, creating a single TIFF image of size up to 224.6 MB. Medium format digitals are geared more towards studio and portrait photography than their smaller DSLR counterparts, the ISO speed in particular tends to have a maximum of 400, versus 6400 for some DSLR cameras.

Methods of image capture

Since the first digital backs were introduced, there have been three main methods of capturing the image, each based on the hardware configuration of the sensor and color filters.

The first method is often called single-shot, in reference to the number of times the camera's sensor is exposed to the light passing through the camera lens. Single-shot capture systems use either one CCD with a Bayer filter mosaic it, or three separate image sensors (one each for the primary additive colors red, green, and blue) which are exposed to the same image via a beam splitter.

The second method is referred to as multi-shot because the sensor is exposed to the image in a sequence of three or more openings of the lens aperture. There are several methods of application of the multi-shot technique. The most common originally was to use a single image sensor with three filters (once again red, green and blue) passed in front of the sensor in sequence to obtain the additive color information. Another multiple shot method utilized a single CCD with a Bayer filter but actually moved the physical location of the sensor chip on the focus plane of the lens to "stitch" together a higher resolution image than the CCD would allow otherwise. A third version combined the two methods without a Bayer filter on the chip.

The third method is called scanning because the sensor moves across the focal plane much like the sensor of a desktop scanner. Their linear or tri-linear sensors utilize only a single line of photosensors, or three lines for the three colors. In some cases, scanning is accomplished by rotating the whole camera; a digital rotating line camera offers images of very high total resolution. The choice of method for a given capture is of course determined largely by the subject matter. It is usually inappropriate to attempt to capture a subject that moves with anything but a single-shot system. However, the higher color fidelity and larger file sizes and resolutions available with multi-shot and scanning backs make them attractive for commercial photographers working with stationary subjects and large-format photographs.

Recently, dramatic improvements in single-shot cameras and RAW image file processing have made single shot, CCD-based cameras almost completely predominant in commercial photography, not to mention digital photography as a whole. CMOS-based single shot cameras are also somewhat common.Filter mosaics, interpolation, and aliasing

In most current consumer digital cameras, a Bayer filter mosaic is used, in combination with an optical anti-aliasing filter to reduce the aliasing due to the reduced sampling of the different primary-color images. A demosaicing algorithm is used to interpolate color information to create a full array of RGB image data.

Cameras that use a beam-splitter single-shot 3CCD approach, three-filter multi-shot approach, or Foveon X3 sensor do not use anti-aliasing filters, nor demosaicing.Firmware in the camera, or a software in a raw converter program such as Adobe Camera Raw, interprets the raw data from the sensor to obtain a full color image, because the RGB color model requires three intensity values for each pixel: one each for the red, green, and blue (other color models, when used, also require three or more values per pixel). A single sensor element cannot simultaneously record these three intensities, and so a color filter array (CFA) must be used to selectively filter a particular color for each pixel.

The Bayer filter pattern is a repeating 2×2 mosaic pattern of light filters, with green ones at opposite corners and red and blue in the other two positions. The high proportion of green takes advantage of properties of the human visual system, which determines brightness mostly from green and is far more sensitive to brightness than to hue or saturation. Sometimes a 4-color filter pattern is used, often involving two different hues of green. This provides potentially more accurate color, but requires a slightly more complicated interpolation process.

The color intensity values not captured for each pixel can be interpolated (or guessed) from the values of adjacent pixels which represent the color being calculated.

Connectivity

Many digital cameras can connect directly to a computer to transfer data:

Early cameras used the PC serial port. USB is now the most widely used method ( Most cameras are viewable as USB Mass Storage), though some have a FireWire port. Some cameras use USB PTP mode for connection instead of USB MSC; some offer both modes.

Integration

Storage

Digital cameras need memory to store data. A wide variety of storage media has been used. These include:

Formats

Future of Digital Cameras
